5Gallon 3 In 1 Barrel Mineral Water Filling Machine
For 20 Liter PET Bottle
This machine is made by stainless steel 304, it has auto washing, filling& capping in one body, with auto uploading barrrel, empty bottle conveying& full bottle conveying, the length can design according to the buyer's workshop.
The machine adpot hot washing.
| Main technical standard |
| Model | QGF-120 | QGF-250 | QGF-300 | QGF-450 | QGF-600 | QGF-900 | QGF-1200 |
| Filling heads | 1 | 2 | 2 | 3 | 4 | 6 | 10 |
| Volume | 20 | 20 | 20 | 20 | 20 | 20 | 20 |
| Barrel size | ¢270*490 | ¢270*490 | ¢270*490 | ¢270*490 | ¢270*490 | ¢270*490 | ¢270*490 |
| Capacity | 120 | 250 | 300 | 450 | 600 | 900 | 1200 |
| Gas pressure | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.4-0.6 | 0.6 | 0.6 | 0.6 |
| Gas consumption | 0.37 | 0.37 | 0.6 | 0.8 | 1 | 1.5 | 1.8 |
| Moto power | 1.38 | 1.75 | 3.8 | 3.8 | 7.5 | 9.75 | 13.5 |
| Rated voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ |
| weight | 680 | 800 | 1500 | 2100 | 3000 | 3500 | 4500
|
Automatic Bottle Loading System
Model: IBW-8/16
Function: wash & disinfect the internal 5 gallon bottle with hot alkali water, detergent
water,cycle water, production water
Technical Parameter
- Washing capacity: 1200 bottles per hour
- Each washing stops washing time: 18 seconnds
- Washing tank: 4pcs ( hot hot alkali water tank, detergent water tank, cycle water tank, production water tank)
- Washing pump 4pcs fixed with each water tank.
Water Filler
Model: RF-8E
Function: to fill the production water into empty bottle,Technical Parameter:
- Filling Nozzle: 8pcs SUS304
- Filling Capacity: 1200 bottle per hour
- Suitable to bottle dimension: 3,5,6 gallon bottle
- Drive motor power 2.2kw 1pc
- Dimension: 1800×1200×2500mm
Feature:
- Gravity style filling nozzle, high filling precision
- Under PLC control, full-automatic working
- SUS304 water bowl, inside polish
- SUS304pipeline, valve and other contact parts
- Automatic alarm system when accident
Caps Chain Plate Capper
capping the bottle by chain plate station
Techincal Parameter:
Capping capacity: 1200BPH
Feature:
Automatic caps arranging,caps washing and caps delivery.
Lack of caps automatic start, full of caps automatic start
Chain plate capping station, steadily & smoothly
SUS304 pipeline, valve and other liquid contacts parts
